Project Description

AIR DUCTS

Sinteco’s Aermet (welded stainless-steel ducts) is the metallic air duct system that was developed in the ’90s. It is used for the distribution of air inside large production rooms, especially for the ones that produce food products having low shelf life and are sensitive to changes in the surrounding environmental conditions. Sinteco’s Aermet (welded stainless-steel ducts) has been carefully designed to ensure the internal surfaces can be cleaned easily. It is ideal for Food, Pharmaceutical and Healthcare sectors where there is requirement for maximum hygiene levels.

Product Specifications

  • Completely welded product inside and outside
  • Suitable for easy and strong washing
  • Resistance to corrosion
  • Absence of any protective coating
  • Compactness of the non-porous surface
  • High bacteria removal during cleaning cycles
  • Low bacteria retentiveness after cleaning cycles
  • Types of insulation – preferably sprayed polyurethane (or other suitable materials)
  • External finishing of insulation with Aluminium or Stainless Steel sheets

Sinteco’s Aermet (coupled folded ducts) is the standard metallic air duct system. It is made of galvanized or stainless-steel and is used for the distribution of air inside large production rooms.

Product Specifications

  • Suitable for dry washing
  • Resistance to corrosion (since material of construction is galvanized or stainless steel)
  • Absence of any protective coating
  • Compactness of the non-porous surface
  • Types of insulation – preferably sprayed polyurethane (or other suitable materials)
  • External finishing of insulation

Sinteco’s Aertex is the textile air duct system that was developed in 1986. It is used for the distribution of air inside large production rooms, especially for the ones that produce food products having low shelf life and are sensitive to changes in the surrounding environmental conditions.

Product Specifications

  • Material of construction: 100% polyester (can be changed based on request); other properties include air pressure resistance, micro-porous surface to control air diffusion levels, Class 1 Fire certification, easy washing, quick drying and optional insulation
  • Uniform distribution of air across large areas
  • Mounting accessories made of stainless-steel for higher durability and prevention of corrosion
  • Customizable shapes and colours
  • Air distribution controlled by turn-key systems
  • Highly competitive costs compared to traditional metallic or polyurethane ducts
  • Easy to handle
  • Zero noise pollution in the working floors
  • Can be mounted on any kind of ceiling material given the low weight of the ducts and accessories
  • Possibility of modifying the duct lines while operations are in progress

CIRCULAR AERTEX

Textile Air Ducts

Sinteco’s Aertex is the textile air duct system that was developed in 1986. It is used for the distribution of air inside large production rooms, especially for the ones that produce food products having low shelf life and are sensitive to changes in the surrounding environmental conditions.

Product Specifications

  • Optimal air distribution
  • Homogeneous air distribution, no air currents created
  • Different air diffusion types based on the height, layout and position of the people in the room
  • Easy to install, dismantling and re-assembling for washing and sanitization operations with a special zip system
  • Exclusive technical industrial fabrics designed for the most advanced aeraulic applications
  • No condensation
  • Available in a wide range of colours

INSULATED CIRCULAR AERTEX

Textile Air Ducts

Sinteco’s Aertex is the textile air duct system that was developed in 1986. It is used for the distribution of air inside large production rooms, especially for the ones that produce food products having low shelf life and are sensitive to changes in the surrounding environmental conditions.

Product Specifications

  • Dismountable double concentric duct system with independent thermal external finish
  • Considerable reductions in energy consumption levels
  • Reduction of the noise levels
  • Highly competitive costs, very economical solution compared to existing traditional distribution systems
  • No condensation
  • Available in a wide range of colours

Textile Air Ducts

Sinteco’s Aertex is the textile air duct system that was developed in 1986. It is used for the distribution of air inside large production rooms, especially for the ones that produce food products having low shelf life and are sensitive to changes in the surrounding environmental conditions.

Product Specifications

  • Reduced encumbrance and different air diffusion settings: particularly suited for environments with low height
  • Homogeneous air distribution, no air currents created
  • Extremely light, easily fixable to all types of ceiling
  • Quick and easy to install at reduced costs
  • No condensation
  • Available in a wide range of colors
